UL 21242 / UL 21242(shielded) Muti-core Cable
Over 80 sorts of UL Certificates wires for selection,meeting your requirements.
For Muti-core Cables we have UL certificated wires as following:
UL21590 UL21242 UL20710 UL4600 UL4622 UL2895
PFA Insulation wire 250 ℃
UL1707 UL1708
UL1709 UL1726 UL1710 UL1716 UL1727
UL1857 UL1860 UL1858 UL1859 UL1882
UL1911 UL1929 UL1930 UL1933 UL10110
UL10129 UL10362 UL10485
UL10486 UL10503 UL10142
PTFE Insulation wire 260 ℃
UL1164 UL1180 UL1198 UL1199
UL1212 UL1213 UL1570 UL1584
UL1815 UL10393 UL1659
FEP Insulation wire 200 ℃
UL1330 UL1332 UL1333
UL1371 UL1538 UL1577 UL1591 UL1592
UL1723 UL1887 UL1901
Annual capacity of other High-temperature wires as below:
1.PFA/FEP/ETFE/PEEK wires:400,000 KMS
2.PTFE tape lapping wires:18,000 KMS
3.Extremely -soft Silicone rubber wire:72,000 KMS
4.Silicone rubber wires with high voltage:20,000 KMS
5.High temperature wires with Shield:28,000 KMS
6.MGT fiberglass lead wires:10,000 KMS
7.EV wires:200,000 KMS
8.Silicone rubber wires with braided fiberglass sheath:18,000 KMS
9.Multi-core cables:40,000 KMS
For Muti-core Cables or UL certificated Muti-core Cables with regular size, we have prepared sample wires in stock all year around, welcome asking for the sample wires.
|
UL code |
21242 |
21242(Shielded) |
|||
|
Voltage |
300V |
300V |
|||
|
Temp |
250℃ |
250℃ |
|||
|
AWG |
Number of cores |
OD(inches) |
Weight |
OD(inches) |
Weight |
|
28 |
2 |
0.0984 |
9.00 |
0.1220 |
18.94 |
|
3 |
0.1063 |
12.00 |
0.1260 |
21.68 |
|
|
4 |
0.1181 |
15.00 |
0.1378 |
26.16 |
|
|
5 |
0.1299 |
18.00 |
0.1496 |
29.77 |
|
|
26 |
2 |
0.1102 |
11.00 |
0.1299 |
21.92 |
|
3 |
0.1181 |
15.00 |
0.1378 |
26.34 |
|
|
4 |
0.1299 |
19.00 |
0.1496 |
30.85 |
|
|
5 |
0.1417 |
23.00 |
0.1614 |
36.23 |
|
|
24 |
2 |
0.1181 |
14.00 |
0.1457 |
26.54 |
|
3 |
0.1260 |
18.00 |
0.1535 |
31.97 |
|
|
4 |
0.1417 |
25.00 |
0.1654 |
38.53 |
|
|
5 |
0.1575 |
30.00 |
0.1811 |
45.16 |
|
|
22 |
2 |
0.1378 |
20.00 |
0.1614 |
32.89 |
|
3 |
0.1457 |
27.00 |
0.1693 |
40.49 |
|
|
4 |
0.1614 |
34.00 |
0.1890 |
50.91 |
|
|
5 |
0.1772 |
41.00 |
0.2047 |
59.85 |
|
|
20 |
2 |
0.1457 |
23.00 |
0.1732 |
38.00 |
|
3 |
0.1575 |
31.00 |
0.1811 |
47.03 |
|
|
4 |
0.1732 |
39.00 |
0.1969 |
57.10 |
|
|
5 |
0.1890 |
48.00 |
0.2165 |
68.19 |
|
|
18 |
2 |
0.1654 |
31.00 |
0.1929 |
48.53 |
|
3 |
0.1772 |
43.00 |
0.2008 |
61.14 |
|
|
4 |
0.1969 |
55.00 |
0.2205 |
75.08 |
|
|
5 |
0.2165 |
67.00 |
0.2402 |
89.57 |
|
|
16 |
2 |
0.1929 |
45.00 |
0.2205 |
64.91 |
|
3 |
0.2087 |
63.00 |
0.2362 |
86.56 |
|
|
4 |
0.2283 |
81.00 |
0.2598 |
112.51 |
|
|
5 |
0.2520 |
100.00 |
0.2835 |
134.35 |
|
